Mimaki JV150 Series inkjet printers go beyond versatility to deliver a remarkable range of applications. Gamut-extending eco solvent inks and variable drop technology enable you to accomplish anything from fine art reproduction to vehicle wraps and more. Or choose dye sublimation inks to create vibrant textiles and soft signage. Ideal for lighter production environments, the JV150 Series printers’ superb quality, color fidelity and flexibility give you the ability to go beyond the expected to deliver exactly what your customers need.
Mimaki JV150 Series inkjet printers go beyond versatility to deliver a remarkable range of applications. Gamut-extending eco solvent inks and variable drop technology enable you to accomplish anything from fine art reproduction to vehicle wraps and more. Or choose dye sublimation inks to create vibrant textiles and soft signage. Ideal for lighter production environments, the JV150 Series printers’ superb quality, color fidelity and flexibility give you the ability to go beyond the expected to deliver exactly what your customers need.
The JV150 Series wide-format printers can be configured for either eco solvent printing for sign and graphics applications or for dye-sublimation printing for textile and apparel transfer sublimation applications.
The SS21 eco solvent ink set for the JV150 includes not only Light Magenta and Light Cyan, but Light Black for deeper dimensional monochromatic and grayscale imaging. The addition of Orange ink widens the color gamut for better accuracy in the color reproduction of food and solid Pantone® colors.
When printing in CMYK, JV150 Series printers can be configured with two ink cartridges per color. Utilizing the UISS (Uninterrupted Ink Supply System) when one cartridge is emptied, the printer automatically switches to the full cartridge to deliver continuous imaging.
Mimaki designed an optimum waveform enabling the print head to jet each ink color at the appropriate jetting angle without losing precise ink droplet circularity.
Variable drop printing combined with MAPS3 (Mimaki Advanced Pass System 3) technology ensures precise and accurate print quality throughout the printing process, greatly reducing the appearance of banding and resulting in a smoother image.
A Mimaki-patented, three-way intelligent heating system results in uniform ink drying across the width of the printer, assuring even image quality.
With eco solvent inks:
|
With dye sublimation inks:
|
| Print system | On-demand piezo, one print head per color 8 channels for a variety of ink configurations |
| Max print width | JV150-130: 53.5 inches (1361 mm) JV150-160: 63.3 inches (1610 mm) |
| Print resolution | 300, 540, 720, 1080, 1440 dpi |
| Maximum media width | JV150-130: 1,371mm (54.0″) JV150-160: 1,620mm (63.8″) |
| Max print speed | JV150-130: 526 SqFt/Hr (48.9 SqM/Hr) JV150-160: 605 SqFt/Hr (56.2 SqM/Hr) |
| Ink type | Mimaki SS21 Eco-Solvent: C, M, Y, K, Lc, Lm, Lk, Or Mimaki ES3 Eco-Solvent: C, M, Y, K, Lc, Lm Mimaki Sb54 Dye Sublimation: Bl, M, Y, K, Lbl, Lm |
| Ink capacity | 440ml cartridges standard |
| Max roll weight | 88 lbs. (40 kg) |
| Max media thickness | 1.0 mm |
| Operational environment | Temp: 59˚ – 86˚ F (15˚ – 30˚ C) 35-65% RH (non-condensing) |
| Connectivity | USB 2.0 |
| Power supply | Single-phase AC 100-120V (AC 220-240V) x2 |
| Power consumption | 100V: 1.44kW × 1 or less, 200V: 1.92kW × 1 or less |
| Dimensions (W × D × H) | JV150-130: 98 x 28 x 71 inches (249 x 71 x 145 cm) JV150-160: 108 x 28 x 71 inches (274 x 71 x 145 cm) |
| Weight | JV150-130: 353 lbs. (160 kg) JV150-160: 408 lbs. (185 kg) |
Eco Solvent ink (SS21) | Cyan | Magenta | Yellow | Black | Light Cyan | Light Magenta | Light Black | Orange |
| 2L MBIS Pack* | SPC-0588C | SPC-0588M | SPC-0588Y | SPC-0588K | SPC-0588LC | SPC-0588LM | SPC-0588LK | SPC-0588OR |
| 440ml cartridge | SPC-0501C | SPC-0501M | SPC-0501Y | SPC-0501K | SPC-0501LC | SPC-0501LM | SPC-0501LK | SPC-0501OR |
Eco Solvent ink (ES3) | Cyan | Magenta | Yellow | Black | Light Cyan | Light Magenta | Light Black | Orange |
| 440ml cartridge | SPC-0440C | SPC-0440M | SPC-0440Y | SPC-0440K | SPC-0440LC | SPC-0440LM | ||
Dye Sublimation ink (Sb54) | Blue | Magenta | Yellow | Black | Light Blue | Light Magenta | Light Black | Orange |
| 2L MBIS Pack* | SB54-BLT-2L | SB54-MT-2L | SB54-YT-2L | SB54-KT-2L | SB54-LBT-2L | SB54-LMT-2L | ||
| 440ml cartridge | SB54-BLT-44 | SB54-M-44 | SB43-Y-44 | SB54-K-44 | SB54-LBL-44 | SB54-LMT-44 |
*Use of the 2L Bulk Ink Packs may require purchase of a MBIS unit.
The Mimaki JV150 Series Wide Format Inkjet Printers are available by special order only. If you’d like to order please contact us by filling out the form below or by calling us at 841-7683.
